| Battery Type |
Lead-acid or Lithium-ion |
| Battery Voltage Range (V) |
40-60 |
| Max. Charging Current (A) |
120 |
| Max. Discharging Current (A) |
120 |
| Charging Strategy for Li-ion Battery |
Self-adaption to BMS |
| Number of Battery Input |
1 |
| Max PV Input Power (W) |
6500 |
| Max PV Input Voltage (V) |
500 |
| Start-up Voltage (V) |
125 |
| MPPT Voltage Range (V) |
150-425 |
| Rated PV Input Voltage (V) |
370 |
| Max Input Short-Circuit Current (A) |
22+22 |
| Max Operating PV Input Current (A) |
13+13 |
| Number of MPPT / Strings per MPPT |
2/1+1 |
| Rated AC Input/Output Active Power (W) |
5000 |
| Max AC Input/Output Apparent Power (VA) |
5500 |
| Peak Power (off-grid) (W) |
2 times of rated power, 10s |
| Rated AC Input/Output Current (A) |
20.8 |
| Max AC Input/Output Current (A) |
22.9 |
| Max Continuous AC Passthrough (A) |
40 |
| Rated Input/Output Voltage/Range (V) |
120/240; 208 0.88Un<U<1.1Un |
| Grid Connection Form |
2L+N+PE |
| Rated Input/Output Grid Frequency/Range |
60Hz/55Hz-65Hz |
| Power Factor Adjustment Range |
0.9-1 |
| Total Current Harmonic Distortion (THDi) |
<3% (of nominal power) |
| DC Injection Current |
<0.5%ln |
| Max Efficiency |
97.6% |
| Euro Efficiency |
96.5% |
| MPPT Efficiency |
>99% |
| Integrated Protection |
DC Polarity Reverse Connection Protection, AC Output Overcurrent Protection, AC Output Overvoltage Protection, AC Output Short Circuit Protection, Thermal Protection, DC Terminal Insulation Impedance Monitoring, DC Component Monitoring, Ground Fault Current Monitoring, Power Network Monitoring, Island Protection Monitoring, Earth Fault Detection, DC Input Switch, Overvoltage Load Drop Protection, Residual Current (RCD) Detection, Surge Protection Level |
| Surge Protection Level |
TYPE II (DC), TYPE II (AC) |
| Communication Interface |
RS485/RS232/CAN |
| Monitor Mode |
GPRS/WIFI/Bluetooth/4G/LAN (optional) |
| Operating Temperature Range |
-40 to +60℃, >45℃ Derating |
| Permissible Ambient Humidity |
0~100% |
| Permissible Altitude |
2000m |
| Noise (dB) |
<30 dB(A) |
| Ingress Protection (IP) Rating |
TYPE3R |
| Inverter Topology |
Non-Isolated |
| Over Voltage Category |
OVC II (DC), OVC IV (AC) |
| Cabinet Size (W*H*D) [mm] |
420×670×233 (Excluding connectors and brackets) |
| Weight (kg) |
30 |
| Warranty |
5 Years/10 Years |
| Type of Cooling |
Intelligent air cooling |
| Grid Regulation |
EN 50549, UNE 217002, NRS 097, IEEE 1547.1, SRD V2.0 |
| Safety EMC/Standard |
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2, FCC, UL 1741 |
